Kenwood PKG-MR3321BT Marine Receiver and Speaker Package

Package Includes:

• One - Kenwood KMR-M332BT Receiver
• Two - Kenwood KFC-1613MRW 6.5" Speakers

Kenwood KMR-M332BT Marine/Powersports/Car Receiver with Bluetooth

Equipped with the Intuitive KENWOOD Music Mix
Up to 5 Bluetooth® devices can be connected to the receiver at the same time, allowing you to take turns streaming music with your friends and family. Dual Phone Connection
While you are connected through Bluetooth, with a touch of a button you can switch between two phones. Control the Receiver from Your Smartphone with the KENWOOD Remote App
A smartphone application can control most basic functions of the receiver over the Bluetooth connection of the paired phone (iPhone or Android). Streaming Music
Listen to popular music applications and music stored on your device with basic audio controls. Designed for Ease of Use
Direct Bluetooth keys allow you to access quickly to answering to and making a call, and entering Bluetooth Audio source. Front USB and AUX Input Compatible with a Variety of USB-Enabled Devices
Easy front panel connection for your compatible USB- enabled devices. These include Mass Storage Class devices like iPods, smartphones, and USB flash drives. The USB input will allow you to charge and control the music playback of your select devices. 13-Band EQ / Digital Time Alignment
13-Band equalizer and DTA gives optimal tuning enhancements for the listener. Playable USB Files
Compatible with a broad range of audio file formats from FLAC and WAV, to MP3, WMA and AAC. Music Codecs
FLAC Playable up to ～96kHz / ～24bit
WAV Playable up to ～44.1kHz / ～16bit
MP3 Playable up to ～48kHz / ～320kbps
WMA Playable up to ～48kHz / ～192kbps
AAC Playable up to ～48kHz / ～320kbps Digital Time Alignment
Sound coming from a variety of speakers located within your car are time aligned to arrive at your ear at exactly the same time. Drive Equalizer
Drive EQ boosts specific frequencies in the audio signal to compensate the negative impact of road noise. System EXPANSION Ready
The KENWOOD receiver has RCA outputs to expand the system to connect to an additional amplifier or powered subwoofer. Variable Color Display
Bright variable color LED's can be adjusted to match your environment. Short Chassis Design
With audio receivers shorter in depth, installation is made easier in a wider range of cars. Conformal Coating
Improved moisture resistance of the circuit boards to prevent corrosion. SiriusXM Radio Ready
Access additional music, sports and entertainment content on the go with SiriusXM Radio.
(Optional SiriusXM tuner required, sold separately) Spanish and French Text Display
On-screen display menu now available in Spanish and French. Wired Remote Control (Optional)
Remote control and remote extension cables are optionally available. Specifications FM
Frequency Range(MHz): 87.9MHz to 107.9MHz
(Frequency step): (200kHz)
Usable Sensitivity: 8.2dBf
S/N:30dB: (0.71μV/75Ω)
Quieting Sensitivity: 17.2dBf
DIN S/N:46dB: (2.0μV/75Ω)
Frequency Response(±3.0dB): 30Hz to 15kHz
S/N(dB): 64.0dB(MONO)
Stereo Separation: 40dB(1kHz) MW (AM)
Frequency Range(kHz): 530kHz to 1700kHz
(Frequency step): (10kHz)
Usable Sensitivity: 29dBμ (28.2μV)
Preout Level(mV)/Load -Unbalanced: 4000mV/10kΩ
Preout Impedance(Ω): =<600Ω
Speaker Impedance(Ω): 4 to 8Ω USB
I/F: USB: USB 1.1 / 2.0 High Speed
File System: FAT12 / 16 / 32
Maximum Supply current: DC5V(DC logo) 1.5A
Frequency Response: 20Hz to 20kHz(±1dB)
S/N Ratio (dB): 98dB(1kHz)
Dynamic Range: 93dB
Channel Separation: 91dB
MP3 Decode: Compliant with MPEG-1/2 Audio Layer-3
WMA Decode: Compliant with Windows Media Audio
AAC Decode: AAC-LC ".aac",".m4a" files
WAV Decode: Linear-PCM
FLAC Decode: FLAC file (Up to 24bit/96kHz) AUX
Input: Frequency Response: 20Hz to 20kHz ±3dB
Input Maximum Voltage: 1000mV
Input Impedance: 30kΩ AMP
PWR(MAX): 50Wx4
Full Bandwidth Power
(at less than 1%THD): 22Wx4 TONE
Band1: 62.5Hz ±9dB
Band2: 100Hz ±9dB
Band3: 160Hz ±9dB
Band4: 250Hz ±9dB
Band5: 400Hz ±9dB
Band6: 630Hz ±9dB
Band7: 1kHz ±9dB
Band8: 1.6kHz ±9dB
Band9: 2.5kHz ±9dB
Band10: 4kHz ±9dB
Band11: 6.3kHz ±9dB
Band12: 10kHz ±9dB
Band13: 16kHz ±9dB Bluetooth
Version: Bluetooth 4.2
Frequency Range: 2.402 to 2.480GHz
RF Output Power (E.I.R.P.): +4dBm (MAX), Power Class 2
Maximum Communication range: Line of sight approx.10m(32.8ft) Profile
HFP 1.7.1 (Hands Free Profile)
SPP(Serial Port Profile)
PBAP(Phonebook Access Profile)
A2DP(Advanced Audio Distribution Profile)
AVRCP 1.6.1 (Audio/Video Remote Control Profile) GENE
Operating voltage: 12V DC car battery
Installation Size (W x H x D): 7 3/16" x 2 1/16" x 3 15/16"
Net Weight: 1.5 lbs.
(Trim plate and Mounting sleeve: Included)

Kenwood KFC-1613MRW 6.5" Marine/Powersports Speakers - White

KFC-1613MRW 6-1/2" Marine/Motorsports 2-Way Speakers

• 6-1/2" 2-Way Speakers
• Peak Input Power : 100W
• Rated Input Power: 30W
• Waterproof Polypropylene Cone
• Balanced Dome Tweeter
• UV Resistant Grille

General Features

• Peak Input Power: 100W
• Rated Input Power: 30W
• Impedance: 4Ω
• Woofer Features: 6-1/2 inch Water Resistant PP Cone
• Tweeter Features: Water Resistant Balanced Dome
• Sensitivity: 87 dB/ W / m
• Frequency Response: 60Hz-20kHz
• Cutout Diameter: 5 inch; 127mm
• Mounting Depth: 2-5/16 inch; 58mm
