Kicker 44TCWC102

Features

• Fits Perfectly Under Or Behind A Seat
• Genuine CompC Subwoofer
• Custom Port Design
• Made Of Heavy MDF
• Spring Loaded Speaker Terminal
• Thick Black Carpet Protects the Enclosure
• Embroidered KICKER Logo
• Works Perfectly with CX300.1
• This enclosure works best with 300 watts of recommended power. See below for more details.

Specifications

• Subwoofer (in, cm) 10, 25
• Impedance (Ohms) 2
• Power Watts (peak/RMS) 600/300
• Sensitivity (dB 1w/1m) 93.8
• Box Top Depth (in, cm) 4, 10.2
• Box Bottom Depth (in, cm) 7-5/8, 19.4
• Box Height (in, cm) 15, 38.1
• Box Width (in, cm) 21-1/2, 54.6
• Recommended Amplifier CX300.1

Alpine R2-DB8V-TRK Dual 8” Halo R-Series Preloaded Truck Subwoofer Enclosure with ProLink™

Features

• Groundbreaking Alpine Halo Design
• ProLink™ Ported Enclosure
• Expandable Width from 40" to 51"
• Compact, Under-the-Seat Installation in Most Full-Size Trucks
• Integrated Amplifier Tray (not applicable with all vehicles), compatible with Alpine Mono Amps (sold separately)
• Rubber, Modular Stackable Foot Design Accommodates Uneven Truck Floor Areas
• Ported Enclosures with Next-Gen R-Series Subwoofers
• Front Link Alpine Branded Bracket
• Side-Firing Cabin Loading Ports
• Premium Alpine Wire Terminals
• Twist-Lock Grille Mount System
• CARB Compliant 5/8" MDF Construction
• Premium Black Carpet

Confirmed Fitment

• 2018-Up Chevy Silverado Crew Cab
• 2015-Up Ford F-150 Crew Cab
• 2018-Up GMC Sierra Crew Cab
• 2018-Up RAM 1500 Crew Cab
• 2020-Up Jeep® Gladiator JT (Fits under seat)
• Jeep® Wrangler JK/JL (Fits in trunk space, not under seat)

Specifications

What's in the Box

• Subwoofer Enclosures Preloaded with (2) R2-W8D2 8” R-Series Subwoofers
• Front and Rear ProLink™ Brackets
• Alpine Front Logo Cover
• Two Amplifier Tray Brackets
• Owner’s Manual

Atrend Bbox A602-10CP

• Width 50.25
• Height 7.875
• Depth 22.375
• Mounting Depth 4.375
• Gross Cubic Feet Per Side 0.83
• Net Cubic Feet Per Side 0.83
• Excursion 3.375

• Fits under your truck seat or in the trunk
• Forced-Air Cooling
• Pre-wired to a single 2-Ohm terminal

Bassworx SW210B

• Wedge shape profile
• Compact design
• Push post terminal
• 3/4” baffle & 5/8” MDF throughout
• Top grade carpeting
• Width 28.75"
• Depth 8.75"
• Mounting Depth 6.25"
• Height 13"
• Volume 1.08cf

Kicker 45DL7R122 Dual 12" Solo-Baric L7R Loaded Subwoofer Enclosure - 2 Ohm

Features

Specifications

What's in the box

Atrend Bbox A202-10CP

• Width 57
• Height 7.25
• Depth 13.25
• Mounting Depth 6.5
• Gross Cubic Feet Per Side 0.63
• Net Cubic Feet Per Side 0.63

Kicker Dual 10" Subwoofer Bass Package - PPAUDC16

Package Includes:

• One - Kicker 48DCWR102 Dual 10" Loaded Sub Enclosure
• One - AudioControl A800.1 Altitude Sub Amp

Kicker 48DCWR102 Dual CompR 10" Loaded Subwoofer Enclosure - 2 Ohm

Upgrade your ride with legendary KICKER bass—the CompR Dual 10-Inch Subwoofer Enclosure delivers powerful, deep, and consistent low-end performance. Designed for maximum efficiency, it features a single 2Ω terminal, ensuring seamless integration with your amplifier for optimal output.

Precision Engineering for Superior Sound
Advanced Suspension and Heat Management – Keeps bass powerful and distortion-free, even at high volumes.
Santoprene® Surround with Signature Red Double Stitching – Ensures durability and a strong bond with the polypropylene woofer cone.
SoloKon™ Technology – Fuses the cone to the vented back brace, improving cooling and reducing distortion for clean, hard-hitting bass.
Forced Air Cooling System – Runs 25% cooler than previous models, increasing longevity and reliability.

Built for Performance and Style
Front-Facing Tuned Port – Enhances acoustic efficiency, delivering louder bass with minimal amplifier power.
Sleek Black Carpeted Enclosure – Provides a refined, durable finish that looks great in any setup.
Power Handling: Best suited for 800 watts of recommended power.

Experience booming bass and unmatched reliability with the KICKER CompR Dual 10” Subwoofer Enclosure—engineered for high-performance sound that takes your audio to the next level.

Specifications
TYPE: Dual
NO. OF WOOFERS/SIZE (in, cm): (2) 10, 25
IMPEDANCE (Ohms): 2
Recommended Amplifier Power (watts RMS): 800
Peak Power (watts, per ANSI/CTA-2031-A): 1600
SENSITIVITY (dB 1w/1m): 94
BOX TOP DEPTH (in, cm): 14-1/2, 36.8
BOX BOTTOM DEPTH (in, cm): 17-5/16,43.9
BOX HEIGHT (in, cm): 14, 35.6
BOX WIDTH (in, cm): 28-7/16, 72.3

AudioControl A800.1 Altitude Subwoofer Amplifier

Take your car audio to new heights with the AudioControl A800.1 Altitude Mono Amplifier, part of the sleek and modern Altitude Series. Built with an anodized matte grey aluminum chassis, it ensures superior thermal dissipation while delivering top-tier power and sound quality. Designed for performance, this amplifier provides robust, high-efficiency output for an immersive listening experience.

Equipped with Valet Mode, the Altitude amplifier protects your system by capping the volume at 25% when activated, preventing accidental damage. It’s also compatible with start-stop systems and electric vehicles, ensuring reliable operation in any setup.

For the ultimate sound experience, pair the Altitude Series amplifiers with AudioControl’s PNW speakers and Space or Spike subwoofers—a combination engineered to deliver pure, uninterrupted power. Spike Mode allows you to connect three 4Ω subwoofers at 1.33Ω, maximizing output while keeping the amplifier cool even during extended high-performance use.

Fine-tune your bass with ParaBASS control knobs, allowing precise customization for deep, punchy low-end response. Your bass, your way.

Under the hood, the A800.1 is built for efficiency and durability:

• Advanced PWM circuitry ensures improved performance and efficiency.
• HEXFET® Power MOSFETs provide ultra-low resistance and fast, reliable switching speeds.
• Premium toroidal transformer minimizes signal distortion for clean power delivery.
• Low ESR capacitors reduce power loss and internal heat buildup.
• Precision metal potentiometers allow accurate tuning with durable construction.
• 500V Class X2 capacitors with self-healing properties offer high-frequency, high-current protection.
• High-efficiency ferrite core inductors optimize power output with minimal energy loss.
• Class D intelligent driver IC with PWM modulation and HEXFET protection delivers outstanding power and efficiency.
• The AudioControl A800.1 Altitude Mono Amplifier is engineered for those who demand exceptional performance, reliability, and pure, powerful sound.
• HEXFET® Power MOSFETs provide ultra-low resistance and fast, reliable switching speeds.
• Premium toroidal transformer minimizes signal distortion for clean power delivery.
• Low ESR capacitors reduce power loss and internal heat buildup.
• Precision metal potentiometers allow accurate tuning with durable construction.
• 500V Class X2 capacitors with self-healing properties offer high-frequency, high-current protection.
• High-efficiency ferrite core inductors optimize power output with minimal energy loss.
• Class D intelligent driver IC with PWM modulation and HEXFET protection delivers outstanding power and efficiency.

The AudioControl A800.1 Altitude Mono Amplifier is engineered for those who demand exceptional performance, reliability, and pure, powerful sound.

Features
High/Low Input Modes
GTO™ Signal Sense
Linkwitz-Riley Crossovers
Start-Stop Compliant
High Power Output in a Sleek Chassis
ParaBASS® Low Frequency Contouring
Valet Mode Option
Optional Remote Level Control (ACR-1)
EV Compliant up to 17V
Spike Mode Enabled

Specifications

Inputs
Preamp Inputs: 2
Line-Level Inputs: 6 V max
Speaker-Level Inputs: 20 V max

Outputs
Rated Continuous (RMS) Power at 14.4V:
400W x 1 @ 4Ω
600W X 1 @ 2Ω
800W x 1 @ 1.33Ω

Remote Level Control
ACR-1 (optional)

Weights and Dimensions
DIMENSIONS: 10.9” W x 6.7” D x 2.1” H
WEIGHT: 6.05 lbs

Performance
S/N Ratio (ref: rated power): 110.2 dBA
THD+N: <0.14%
Power / Ground Wire Gauge: 4 AWG
Recommended Fuse rating: 100A
Valet Mode: Yes
Subsonic Filter: Variable
Linkwitz-Riley X-Over:
    Low Pass
    Freq. Range: 60 Hz to 120 Hz
Bass Processing: ParaBASS®

Atrend Bbox A362-10CP

• Width 50.625
• Height 8.625
• Depth 13.625
• Mounting Depth 6
• Gross Cubic Feet Per Side 0.8
• Net Cubic Feet Per Side 0.8
• Excursion 1.375

Atrend Bbox A402-10CP

• Width 49.25
• Height 7.625
• Depth 13
• Mounting Depth 5.125
• Gross Cubic Feet Per Side 0.85
• Net Cubic Feet Per Side 0.85
• Excursion 1.625

JL Audio CP208LG-W3v3 Dual 8" Low Profile Loaded Subwoofer Enclosure - 2 Ohm
