Hertz HEX 6.5 S-LD-G 6.5" Marine Coaxial Speakers

SPORT option grille HEX coaxial with RGB LEDs lighting option always provide the perfect style for your boat, giving you years of pure fun while cruising, being over engineered and tested for Marine applications. The compact 6.5” speaker, with a depth of only 2.36 in. delivers a detailed and dynamic sound, making every outing memorable.

HEX sport grille can be easily removed to be painted with a custom color perfect for your boat.

Features

Hertz Pure Marine Certified Product stamp featuring the IP65 protection grade, ASTM-D4329 standards for UV resistance and ASTM-B117 for salt fog operability.

High efficiency tweeter designed with FEM simulation to maximize off-axis emission, typical of in-boat install.

Sound-transparent mesh grille with twist and lock locking system, providing an elegant style and a rock-solid protection.

Woofer with 25 mm (1”) voice coil fine-tuned for infinite baffle application featuring silicone insulated lead-wire for durability.

Sealed built-in crossover with resettable solid-state tweeter protection circuit.

Nickel-plated corrosion resistant terminals.

Technologies

RGB Multicolor
Built-in RGB led lighting creates sophisticated atmosphere, adding tons of class to your vessel.

Salt Fog Tested
To satisfy the standards required by ASTM-B117, Hertz Marine products are tested with massive salt fog spray to ensure a complete resistance to corrosion, typical of this atmospheric agent.

IP Certification
IP65

Water Jet Tested
IP65 speakers define all the Hertz Pure Marine Certified products as totally protected against water jets of different entities, making them highly performant in the marine environment.

UV Resistant
According to the severe ASTM-D4329 standards for UV resistance, all the materials used for Hertz Marine products are designed to face long time exposition to UV radiations while cruising on the open sea.

Specifications Size mm (in.): 165 (6.5)
Power Handling - Continuous W: 50
Power Handling - Peak W: 100
Impedance Ohm: 4
Depth mm (in.): 85 (3.25)
Tweeter diaphragm mm (in.): 24 (0.9)
Woofer Voice Coil Ø mm (in.): 25 (1)
Tweeter Voice Coil Ø mm (in.): 13 (0.5)
Frequency Response Hz: 50 ÷ 23k
Woofer Magnet size D x d x h mm (in.): 85 x 32 x 15 (3.35 x 1.26 x 0.59)
Tweeter Magnet size D x h mm (in.): 12,9 x 2 + 11 x 1,9 (0.51 x 0.08 + 0.43 x 0.07)
Weight of one speaker kg (lb.): 1 (2.2)
Woofer Magnet: High density flux ferrite
Tweeter Magnet: Neodymium
Cone: Polypropylene with UV inhibitors
Dome: PEI
Xmech mm (in.): ±4,8 (0.19)

Physical Specifications

A: 172 mm: 6.77 in.
B: 128 mm: 5.04 in.
C: 85 mm: 3.25 in.
D: 60,5 mm: 2.38 in.
F: 24,5 mm: 0.96 in.

• CD Quality Streaming
• IP67 Rated
• Backlit Buttons for Day or Night Use

Hertz HMX 6.5 S-LD-G165 6.5" Marine Coaxial LED Speakers

HMX 6.5 S-LD-G marine coaxial speaker features a sports paintable grille for a perfect match with sporty boats. The coaxial speaker is engineered to operate in open water, pleasing you with the incomparable emotions of music for years on end thanks to the special ASA plastic grilles and polypropylene cone with co-molded Santoprene surround.

The Aramid fiber spider with silicone-insulated lead wire ensures durability and constant performance over time. Parts and assembly methods are designed to meet high-humidity marine environments, ensuring the best audio performance season after season.

Technologies

RGB Multicolor
Built-in RGB led lighting creates sophisticated atmosphere, adding tons of class to your vessel.

Salt Fog Tested
To satisfy the standards required by ASTM-B117, Hertz Marine products are tested with massive salt fog spray to ensure a complete resistance to corrosion, typical of this atmospheric agent.

IP Certification
IP65

Water Jet Tested
IP65 speakers define all the Hertz Pure Marine Certified products as totally protected against water jets of different entities, making them highly performant in the marine environment.

UV Resistant
According to the severe ASTM-D4329 standards for UV resistance, all the materials used for Hertz Marine products are designed to face long time exposition to UV radiations while cruising on the open sea.

Specifications
Size mm (in.): 165 (6.5)
Power Handling - Continuous W: 75
Power Handling - Peak W: 150
Impedance Ohm: 4
Depth mm (in.): 95,6 (3.76)
Tweeter diaphragm mm (in.): 36 (1.4)
Woofer Voice Coil Ø mm (in.): 25 (1)
Tweeter Voice Coil Ø mm (in.): 20 (0.8)
Frequency Response Hz: 50 ÷ 25k
Woofer Magnet size D x d x h mm (in.): 78,5 x 32 x 17 (3.09 x 1.26 x 0.67)
Tweeter Magnet size D x h mm (in.): 19,7 x 3 (0.78 x 0.12)
Weight of one speaker kg (lb.): 1 (2.2)
Woofer Magnet: High density flux ferrite
Tweeter Magnet: Neodymium
Cone: Polypropylene with UV inhibitors
Dome: PEI
Xmech mm (in.): ±6,65 (0.26)

Physical Specifications

A 172,2 mm 6.78 in.
B 128 mm 5.04 in.
C 95,6 mm 3.76 in.
D 69 mm 2.72 in.
F 26,6 mm 1.05 in.

Hertz HMX 7.7 S-LD-G 7.7" Marine Coaxial LED Speakers

HMX 7.7 S-LD-G marine coaxial speaker features a sports paintable grille for a perfect match with sporty boats. The coaxial speaker is engineered to operate in open water, pleasing you with the incomparable emotions of music for years on end thanks to the special ASA plastic grilles and polypropylene cone with co-molded Santoprene surround.

The Aramid fiber spider with silicone-insulated lead wire ensures durability and constant performance over time. Parts and assembly methods are designed to meet high-humidity marine environments, ensuring the best audio performance season after season.

Technologies

RGB Multicolor
Built-in RGB led lighting creates sophisticated atmosphere, adding tons of class to your vessel.

Salt Fog Tested
To satisfy the standards required by ASTM-B117, Hertz Marine products are tested with massive salt fog spray to ensure a complete resistance to corrosion, typical of this atmospheric agent.

IP Certification
IP65

Water Jet Tested
IP65 speakers define all the Hertz Pure Marine Certified products as totally protected against water jets of different entities, making them highly performant in the marine environment.

UV Resistant
According to the severe ASTM-D4329 standards for UV resistance, all the materials used for Hertz Marine products are designed to face long time exposition to UV radiations while cruising on the open sea.

Specifications
Size mm (in.): 196 (7.7)
Power Handling - Continuous W: 100
Power Handling - Peak W: 200
Impedance Ohm: 4
Depth mm (in.): 113 (4.4)
Tweeter diaphragm mm (in.): 36 (1.4)
Woofer Voice Coil Ø mm (in.): 32 (1.26)
Tweeter Voice Coil Ø mm (in.): 20 (0.8)
Frequency Response Hz: 45 ÷ 25k
Woofer Magnet size D x d x h mm (in.): 90 x 40 x 20 (3.54 x 1.57 x 0.79)
Tweeter Magnet size D x h mm (in.): 19,7 x 3 (0.78 x 0.12)
Weight of one speaker kg (lb.): 1,66 (3.66)
Woofer Magnet: High density flux ferrite
Tweeter Magnet: Neodymium
Cone: Polypropylene with UV inhibitors
Dome: PEI
Xmech mm (in.): ±8,5 (0.33)

Physical Specifications

A: 196 mm: 7.7 in.
B: 158 mm: 6.2 in.
C: 113 mm: 4.4 in
D: 79 mm: 3.1 in.
F: 34 mm: 1.3 in.
