AudioControl SPC-12S4 12" Low Profile Subwoofer - 4 Ohm

Are you ready to take your musical experience to the next level? Look no further than the Space Series Subwoofers! These slim-yet-mighty subwoofers pack a big punch – delivering maximum low-frequency output in a shallow space. The ultimate solution for deep, rich bass in a sleek and slim design. Add in their weather-resistant features and you can enjoy your music in any environment, worry-free. No matter where you are, we know nothing beats blasting your favorite tunes and feeling your mood drastically improve. So what are you waiting for? Get the Space Series Subwoofers and enhance your vehicle’s listening environment by creating a powerful atmosphere of sound. AudioControl has been helping people make good sound great in their cars for over 45 years, and the Space Series Subwoofers are no exception. The fiber matrix injection molded polypropylene cone ensures that every note is reproduced to perfection, so you can feel the bass hit. The 3-layer high temp voice coil former means they can handle even the most intense bass without breaking a sweat. And don’t worry about distortion ruining your jams – these subwoofers feature an optimal thermal efficiency design to ensure that your bass stays clean and clear. Not only do these subwoofers sound amazing, they’re also built tough. With their weather-resistant design and removable grille you can enjoy your music even if your vehicle likes to play off-road. Features
Low-Profile Shallow Mount Subwoofer
Fiber Matrix Injection Molded Polypropylene Cone
Weather-Resistant Design
3-Layer High Temp Voice Coil Former
Optimal Thermal Efficiency
Wrap-Sealed Rubber Gasket to Protect Enclosure Interior
Removable Subwoofer Grille Included

Specifications

Thiele/Small Parameters
Nominal Impedance (Z): 4 ohms
DC Resistance (Re): 3.2 ohms
Resonance Frequency (Fs): 30.7061 Hz
Piston Area (Sd): 0.0511 m2
Force Factor (BL): 12.4924 T.m
Mechanical Q Factor (Qms): 3.7494
Electrical Q Factor (Qes): 0.5764
Total Q Factor (Qts): 0.4996
Sensitivity 1W/M (SPL): 87.3024
Mechanical Comp (Cms): 0.1844 mm/N
Moving Mass (Mms): 145.7101 g
Linear Excursion (Xmax): 9 mm
Volume Acoustic Comp (Vas): 67.1494 Ltr/2.371348 cu ft
Reference Efficiency (NO.): 0.32% RMS
Power (Pe): 400 Watts
Frequency Response: 20-250 Hz
Voice Coil Diameter: 2.5 in/63.5 mm
Displacement: 0.0619 cu ft/1.752 Ltr Dimensions
Overall Dimensions: 12.37 in/316 mm
Cut Out Diameter: 11.10 in/282 mm
Mounting Depth: 3.94 in/100 mm
Mounting Height (w/o Grille): 0.71 in / 18mm
Mounting Height (w/ Grille): 1.42 in/36mm Ported Enclosure
External Dimensions: 24.00″ W × 15.00″H × 15.00″D
Net Internal Volume: 2.02 ft3
Total Internal Volume: 2.28 ft3
Gross External Volume: 3.01 ft3
Material Thickness: 0.75″
Tuning Frequency: 40 Hz
Port Area” 27.00 inch2
Port Inlet: 2.00″W× 13.50″H
Port Length: 16.25″
F3 (Hz): 40 Sealed Enclosure
External Dimensions: 32″ W × 15.00″H × 7.00″D
Net Internal Volume: 1.25 ft3
Total Internal Volume: 1.31 ft3
Gross External Volume: 1.94 ft3
Material Thickness: 0.75″
F3 (Hz): 51
Qtc: 0.765

AudioControl THREE.2 In-Dash Equalizer/Crossover with Aux Inputs

If you want great sound and love to “tweak” your system then you will truly appreciate the AudioControl THREE.2. Affectionately called the “EQ on steroids” the THREE.2 is a high-end pre-amplifier that offers equalization and crossover controls for enhanced sound quality. Multiple audio inputs both front and rear allow for maximum connectivity with all of your favorite source units. While being housed in a compact ½ DIN sized chassis the THREE.2 is truly a feature-laden processor. The THREE.2 starts with four stereo equalization filters including AudioControl’s proprietary Para-BASS controls which give subwoofers extra kick and detail as needed. It also features a 4 channel 2-way 24 dB/octave car audio crossover with a fader. To round out the package the THREE.2 also includes a subwoofer level control master volume control and the ability to select the back lighting illumination color between Cool Blue and Hot Red. Given that many of today’s audio enthusiasts like to carry their music with them the THREE.2 is equipped with dual 3.5mm auxiliary input jacks located on the front and rear of the chassis. This helps facilitate the permanent installation of cabling or lets a user plug in their portable audio device on the fly. Like all AudioControl autosound products the THREE.2 is built in our factory in the Pacific Northwest USA and carries a full 5-year parts and labor warranty when installed by an authorized dealer like Car Toys.

Features

• Stereo graphic equalization
• Front and Rear Dual Auxiliary inputs
• Para-BASS® low frequency contouring
• Selectable Cool Blue or Hot Red back-lighting
• 24dB/Octave Linkwitz Riley crossover
• Pre-amp gain of 20dB
• Line driver: 13 volts peak output
• Subwoofer level control
• High headroom PWM switching power supply
• Master volume and fader control

Specifications

Inputs
Preamp Inputs: 1 (2 channels)
Input Gain: 0-20dB
Aux Inputs: 2 (⅛” stereo)
Input Impedance: 20kΩ Outputs
Preamp Outputs: 3 (6 channels)
Maximum Output Level: 9.5Vrms
Output Impedance: 150Ω Performance
Total Harmonic Distortion: 0.01%
Frequency Response: 20Hz-20kHz
Signal to Noise: 110dB
Equalizer Frequencies: 40Hz-80Hz (parametric), 125Hz, 1.25kHz, 10kHz
Equalization Cut/Boost: ±12dB
Crossover type: 24dB/octave Linkwitz-Riley
Factory Crossover Setting: 90Hz Control
Remote In General
Power Supply: High Headroom PWM Switching
Current Draw: 250mA
Recommended Fuse Rating: 1A Weights & Dimensions
Dimensions: 6.75”W x 5”D x 1”H
Weight: 2.0lbs (0.9kg) In the Box
Three.2
Mounting Brackets
Power Connector
Manual
Warranty
