• 7" Touchscreen Display
• Wired Apple Carplay and Android Auto
• PowerStack™ Capable

JVC KW-M560BT 6.8" Media Receiver with Apple CarPlay, Android Auto and USB Mirroring

Smartphone Intergration

Sound Optimization

Bluetooth® Wireless Technology

Internet Radio/Digital Radio

General

Technical Specifications

• 11" WXGA Floating CapacitiveTouchscreen Display
• Wireless/Wired Apple CarPlay and Android Auto
• Hi-Res Audio Playback (96kHz / 24bit)

• 6.8" WVGA Capacitive Touchscreen Displayl
• Wired Apple CarPlay and Android Auto
• USB Mirroring for Android

• 6.95" WVGA Resistive Touchscreen Display
• Wireless/Wired Apple CarPlay and Android Auto
• 4 Camera Inputs

Kenwood DNX997XR 6.8" DVD Receiver with Apple CarPlay and Android Auto

Advanced Navigation

Smartphone Connectivity

The Best Audio Experience

Safe Driving

Additional Features

JVC KW-M560BT 6.8" Media Receiver with Apple CarPlay, Android Auto and USB Mirroring

Smartphone Intergration

Sound Optimization

Bluetooth® Wireless Technology

Internet Radio/Digital Radio

General

Technical Specifications

• 7" WXGA Capacitive Touchscreen Display
• Wireless/Wired Apple CarPlay and Android Auto
• iDatalink® Maestro Compatible

JVC KW-V960BW 6.8" CD/DVD Receiver with Wireless Apple CarPlay and Android Auto

Mirroring for Android Phones

Mirroring for iPhone and Android Phones

Highlights

Sound Optimization

Bluetooth® Wireless Technology

Bluetooth Voice Recognition

Internet Radio/Digital Radio

General

Specifications

Kenwood DMX7709S 6.8" Media Receiver with Apple CarPlay and Android Auto

The Best Audio Experience

Safe Driving

Additional Features

Specifications

• 6.95" Capacitive Touchscreen Display
• Wireless/Wired Apple CarPlay and Android Auto
• iDatalink® Maestro Compatible

Kenwood DMX809S Media Receiver with CMOS-740HD HD Backup Camera

Package Includes

• One - Kenwood DMX809S Media Receiver
• One - Kenwood CMOS-740HD HD Backup Camera
• One - Car Toys Key Chain

Kenwood DMX809S 6.8" Media Receiver with Wireless Apple CarPlay and Android Auto

Smartphone Connectivity

Safe, Smart and Comprehensive Control with Apple CarPlay
Apple CarPlay is a safer way to use your iPhone in the car. Simply talk to Siri or touch the receiver’s display to get directions from Apple Maps, make phone calls, listen to voicemail, send and receive texts, and listen to music from Apple Music or your favorite 3rd party streaming services like Pandora and Spotify, all in a way that allows you to stay focused on the road. With the latest iOS version (iOS 12.0 and higher), 3rd party navigation apps like Google Maps™ and Waze™ are also supported.

KENWOOD Wi-Fi receivers now support Apple CarPlay wirelessly (compatible phone required).

Android Auto for Easy Connectivity
Android Auto was designed with safety in mind, helping you to minimize distractions and stay focused on the road. KENWOOD’s multimedia receivers combine an intuitive voice controlled interface with a large touch screen and superior sound quality, making it the perfect complement for your in-car life. You can even listen to and control music from your favorite streaming services like Pandora and Spotify. Navigate to where you need to with Google Maps or Waze. KENWOOD Wi-Fi receivers also support Android Auto wirelessly (compatible phone required).

To use Android Auto on your car display, you’ll need an Android Auto compatible vehicle or aftermarket stereo, an Android phone running Android 6.0 or higher, and the Android Auto app.

True Mirroring via USB, 2-Way Touch Control for Android
Allows you to display and control your Android smartphone on the screen of the receiver. You can enjoy your favorite apps on a large display and with impressive sound quality. Before starting, just install the free app “Mirroring OA for KENWOOD” on your smartphone and connect it to KENWOOD receiver via a USB cable and Bluetooth.

Mirroring for KENWOOD App
For more information, visit here.

HDMI Input
Display your smartphone screen or other device via an HDMI cable (and third party adapter as applicable) on the monitor. KCA-HD200 optional HDMI cable sold separately.

Streaming Music
Listen to popular music applications and music stored on your device with basic audio controls.

Equipped with the Intuitive KENWOOD Music Mix
Up to 5 Bluetooth® devices can be connected to the receiver at the same time, allowing you to take turns streaming music with your friends and family.

Dual Phone Connection
While you are connected through Bluetooth, with a touch of a button you can switch between two phones.

Control the Receiver from Your Smartphone with the KENWOOD Remote App S
A smartphone application can control most basic functions of the receiver over the Bluetooth connection of the paired phone (iPhone or Android).

KENWOOD Portal App
Display image files stored in your iPhone or Android on the receiver's photo frame widget and/or wallpaper.

The Best Audio Experience

Optimal Sound Performance with 13 Band Graphic EQ and Time Alignment
Use the graphic equalizer to tailor the sound quality to your unique tastes. Additional sound staging is available with the Time Alignment feature, designed to provide optimal sound performance.

Playable Video & Audio Files
You can play back from USB devices audio and video files compressed in various formats.
Video Codecs MPEG4, H.264, MKV, and WMV: playable up to 1920 × 1080p
Music Codecs FLAC and WAV Playable up to ~192kHz / ～24bit

Safe Driving

Enhanced Vehicle Intergration
Compatible with both the Automotive Data Solutions iDatalink Maestro RR and RR2 (sold separately)* for enhanced system vehicle integration. In addition to providing the seamless factory integration experience you have become accustomed to with the RR, these models feature expanded support when connected to the RR2, including an Advanced Driver Assistance Systems (ADAS) Widget, Customizable Accessory Controls, and compatibility with specific ESCORT radar detector systems (sold separately).

*Available features vary by vehicle

Rear View Camera Input with Parking Guidelines
An optional rear view camera enhances safety while backing up and monitoring behind your vehicle. Built-in, adjustable parking guidelines further add to its effectiveness.

3 Camera Inputs
To enable a smarter driving experience, receivers featuring 3 camera inputs allow for the utmost in convenience, flexibility, and safety. With 3 camera inputs, you can connect a front camera, a rear camera and a third camera which can be used for trailers or caravans. Alternatively, 3 camera inputs support several other configurations, including the connection of 2 blind spot cameras and a reverse camera. Camera switching is available using on screen controls and manual switchers.

Additional Features

Convenient and Easy-to-Use Capacitive Touch Panel
Provides a high contrast ratio, crystal clear display and vivid text. Easy to use widgets provide access to information screens with a swipe.

SiriusXM Radio Ready
Access additional music, sports and entertainment content on the go with SiriusXM Radio. (Optional SiriusXM tuner required, sold separately)

Built-in HD Radio Tuner
HD Radio has the best selection of local radio with amazing features and no monthly fees. HD Radio provides CD sound quality from digital FM stations and FM sound quality from digital AM stations. You can even access additional HD multicasting stations that are not available on traditional analog radio.

Short Chassis Design
Only 85mm of depth for more flexible installation

Remote Control (Optional)
This receiver unit can be operated using the optional remote control KCA-RCDV340.

Specifications

Monitor
Section: Picture size: 6.75 inches(diagonal) wide
W x H: 151.8 mm x 79.7 mm, 6 x 3-1/7 inch
Display system: TN LCD panel
Drive system: TFT active matrix system
Number of pixels: 1,152,000 - 800H x 480V x RGB
Effective pixels: 99.99%
Pixel arrangement: RGB striped arrangement
Back lighting: LED

USB I/F
Section: Connector Type: Type-A
USB Standard: USB2.0 Full Speed / High Speed
File System: FAT 16/32, exFAT
Maximum Power Supply Current: DC5V=1.5A
D/A Converter: 24Bit
Audio Decoder: MP3 / WMA / AAC / WAV / FLAC
Video Decoder: MPEG1/2,MPEG4 / WMV / H.264 / MKV
Frequency response
- 192k Sampling: 20 to 20,000 Hz
- 96k Sampling: 20 to 20,000 Hz
- 48k Sampling: 20 to 20,000 Hz
- 44.1k Sampling: 20 to 20,000 Hz
Total harmonic distortion 1kHz: 0.010%
Signal to Noise ratio: 98.5dB
Dynamic range: 89dB

Wi-Fi
IEEE Standard: 802.11 a/b/g/n/ac
Frequency Range: Dual Band ( 2.4GHz / 5GHz )
Channels: Auto(1-11ch)
Auto(149,153,155,157,161ch)
Transfer rates (MAX): 11a:54 Mbps / 11b: 11 Mbps
11g: 54 Mbps / 11n:150 Mbps / 11ac:433 Mbps

Bluetooth Section
Technology: Bluetooth Ver5.0
Frequency: 2.402 to 2.480 GHz
Maximum Communication range: Line of sight approx.10m(32.8ft)
Audio Codec: SBC / AAC
Multi Profile Support: Multi Profile
Profile: HFP (V1.8) (Hands Free Profile)
SPP (Serial Port Profile)
A2DP (V1.3.2) (Advanced Audio Distribution Profile)
AVRCP (V1.6.2) (Audio/Video Remote Control Profile)
PBAP (Phonebook Access Profile)

HDMI I/F
Section: Connector Type: Type-D
Input Resolution: VGA (640x480p @59.94Hz/60Hz)
480p (720x480p @59.94Hz/60Hz)
Input Audio Type: 32K/44.1K/48K/88.2K/96K/176.2K/192K 16/20/24-bit Linear PCM

DSP Section
Equalizer: 13Band
Band Frequency: 62.5/100/160/250/400/630/1k/1.6k/2.5k/4k/6.3k/10k/16k[Hz]
Gain: -9/-8/-7/-6/-5/-4/-3/-2/-1/ 0/ 1/ 2/ 3/ 4/ 5/ 6/ 7/ 8/ 9 [dB]
Tweeter Gain: -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 [dB]
HPF Frequency: Through/30/40/50/60/70/80/90/100/120/150/180/220/250[Hz]
Slope: -6/-12/-18/-24[dB/Oct.]
Gain: -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 dB
LPF Frequency: 30/ 40/ 50/ 60/ 70/ 80/ 90/ 100/ 120/ 150/ 180/ 220/ 250 Hz/ Through
Slope: -6/ -12/ -18/ -24 dB/Oct.
Gain: -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 dB
Phase: Normal/ Reverse
Tweeter HPF Frequency: 1k/1.6k/2.5k/4k/5k/6.3k/8k/10k/12.5k [Hz]
Slope: -6/ -12 [dB/Oct.]
Gain: -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 [dB]
Phase: Normal/ Reverse
Mid Range HPF Frequency: Through/30/ 40/ 50/ 60/ 70/ 80/ 90/ 100/ 120/ 150/ 180/ 220/ 250[Hz]
Slope: -6/ -12 [dB/Oct.]
Mid Range LPF Frequency: 1k/1.6k/2.5k/4k/5k/6.3k/8k/10k/12.5k/Through [Hz]
Slope: -6/ -12 [dB/Oct.]
Gain: -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 [dB]
Phase: Normal/ Reverse
Subwoofer LPF Frequency: 30/ 40/ 50/ 60/ 70/ 80/ 90/ 100/ 120/ 150/ 180/ 220/ 250/ Through [Hz]
Slope: -6/ -12 [dB/Oct.]
Gain: -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 [dB]
Phase: Normal/ Reverse

Digital FM
Frequency Range: 87.9MHz to 107.9MHz
(Frequency step): (200kHz)
Frequency Response: 20 Hz to 20 kHz
(±3.0 dB)
S/N: 75 dB(STEREO)

Digital AM
Frequency Range: 530kHz to 1700kHz
(Frequency step): (10kHz)
Frequency Response: 40Hz to 15kHz (±3.0 dB)
S/N: 70 dB(STEREO)

FM
Frequency range (Frequency step): 87.9MHz to 107.9MHz (200kHz)
Usable sensitivity: 7.2 dBf
S/N:30dB: 0.63 μV / 75 Ohms
Quieting sensitivity: 15.2 dBf
DIN S/N:46dB: 1.58 μV / 75 Ohms
Frequency response: 30Hz to 15kHz (±3.0dB)
S/N(dB): 68 dB(MONO)
Selectivity: Over 80dB (±400kHz)
Stereo separation: 40 dB(1 kHz)

AM
Frequency range (Frequency step): 530kHz to 1700kHz (10kHz)
Usable sensitivity: 29 dBμ (28.2μV)

Video
Color system of external video input: NTSC/PAL
External video input level (RCA jacks): 1 Vp-p / 75 Ohms
External video input level (Mini jacks): 1 Vp-p / 75 Ohms
External audio max input level (RCA jacks): -
External audio max input level (Mini jacks): 2 V / 25 kOhms
Video Input level (RCA jacks): 1 Vp-p / 75 Ohms
Video Output level (RCA jacks): 1 Vp-p / 75 Ohms

Audio
Maximum Power Output (Front & Rear): 50Wx4
Typical Power Output (Front & Rear): Full Bandwidth Power (at less than 1%THD) 22Wx4
Output frequency band: 20 to 88,000Hz
Preout level (V): 5V / 10kOhms
Preout impedance (Ohm): =< 600 Ohms
Speaker Impedance (Ohm): 4 to 8 Ohms

General
Operating voltage: 12V DC Car Battery
Installation Dimensions (Main Unit Installation size) WxHxD: 7-1/16. x 3-15/16 x 2-15/16 inch
Installation Dimensions (with Sleeve) WxHxD: 7-3/16 x 4-3/8 x 2-15/16 inch
Weight Main unit: 2.7 lb (Trim plate and Mounting sleeve: Included)

Kenwood CMOS-740HD HD Backup Camera

High Definition View
Displaying the image in true 1280 x 720 (720P) High Definition on compatible DNR1007XR, DNR1008RVS, DMX1057XR, DMX1037S, DNX997XR, DDX9907XR, and DMX958XR receivers.

WVGA Camera

HD Camera

HDR (High Dynamic Range)
HDR helps to reduce “blown out highlights” and “crushed blacks” and ensure clear images in challenging environments, including backlit scenes in daylight, streetlight scenes at night and places where light-dark contrast is particularly severe.

W/O HDR

With HDR

12V & 24V Compatible
Cameras work with both 12V and 24V applications.

General Features
Photographed Image: HD (1280 x 720)
Lens: Wide angle, focal length: 1.86mm F:2.0
Frame Rate: 30fps
Angles of View: Horizontal 180°/ Vertical 103°
Operating Voltage: 12V/24V
Operating Temperature: -22℉ to +185℉ / -30℃ to +85℃
IPX: IP67
Output: HD-TVI
Weight: 0.073lbs / 33.2g (without cable)
Dimensions (W x H x D): 1-1/4" x 15/16" x 1" / 31.1mm x23.0mm x25.2mm

Cable Length
Camera Unit side: 9.84ft / 3m
DC Box Unit side: 19.69ft / 6m
Other: 1.64ft / 0.5m

Kenwood DMX958XR Media Receiver with CMOS-740HD HD Backup Camera

Package Includes:

• One - Kenwood DMX958XR Media Receiver
• One - Kenwood CMOS-740HD HD Backup Camera
• One - Car Toys Key Chain

Kenwood DMX958XR 6.75" Media Receiver with Wireless Apple CarPlay and Android Auto

Smartphone Connectivity

Safe, Smart and Comprehensive Control with Apple CarPlay
Apple CarPlay is a safer way to use your iPhone in the car. Simply talk to Siri or touch the receiver’s display to get directions from Apple Maps, make phone calls, listen to voicemail, send and receive texts, and listen to music from Apple Music or your favorite 3rd party streaming services like Pandora and Spotify, all in a way that allows you to stay focused on the road. With the latest iOS version (iOS 12.0 and higher), 3rd party navigation apps like Google Maps™ and Waze™ are also supported.

KENWOOD Wi-Fi receivers now support Apple CarPlay wirelessly (compatible phone required).

Android Auto for Easy Connectivity
Android Auto was designed with safety in mind, helping you to minimize distractions and stay focused on the road. KENWOOD’s multimedia receivers combine an intuitive voice controlled interface with a large touch screen and superior sound quality, making it the perfect complement for your in-car life. You can even listen to and control music from your favorite streaming services like Pandora and Spotify. Navigate to where you need to with Google Maps or Waze. KENWOOD Wi-Fi receivers also support Android Auto wirelessly (compatible phone required).

To use Android Auto on your car display, you’ll need an Android Auto compatible vehicle or aftermarket stereo, an Android phone running Android 6.0 or higher, and the Android Auto app.

Wireless Mirroring for Android
Solution for seamlessly displaying and controlling your smartphone apps on a screen without cables on select Android devices.

HDMI Input
Display your smartphone screen or other device via an HDMI cable (and third party adapter as applicable) on the monitor. KCA-HD200 optional HDMI cable sold separately.

Streaming Music
Listen to popular music applications and music stored on your device with basic audio controls.

Equipped with the Intuitive KENWOOD Music Mix
Up to 5 Bluetooth® devices can be connected to the receiver at the same time, allowing you to take turns streaming music with your friends and family.

Dual Phone Connection
While you are connected through Bluetooth, with a touch of a button you can switch between two phones.

Control the Receiver from Your Smartphone with the KENWOOD Remote App S
A smartphone application can control most basic functions of the receiver over the Bluetooth connection of the paired phone (iPhone or Android).

KENWOOD Portal App
Display image files stored in your iPhone or Android on the receiver's photo frame widget and/or wallpaper.

The Best Audio Experience

High-Resolution Audio Wireless
High-Resolution Audio is high-quality sound that exceeds CD standard. High-Resolution audio captures and beautifully expresses all the details of your favorite music. Through ultra-high and low frequencies, immerse yourself in a rich and high-quality listening experience. Select KENWOOD receivers now support Hi-Resolution Audio Wirelessly via LDAC. LDAC is an audio coding technology that enables the transmission of High-Resolution Audio over a Bluetooth connection.

Optimal Sound Performance with 13 Band Graphic EQ and Time Alignment
Use the graphic equalizer to tailor the sound quality to your unique tastes. Additional sound staging is available with the Time Alignment feature, designed to provide optimal sound performance.

High Quality Audio Parts Supporting High-Resolution Audio Reproduction
To ensure the best possible sound quality, the receivers use custom-made and carefully selected parts, such as audio quality power supply capacitors and high quality coupling capacitors. These parts are further optimized through meticulous tuning of the component values and circuit paths.

Playable Video & Audio Files
You can play back from USB devices audio and video files compressed in various formats. Video Codecs MPEG4, H.264, MKV, and WMV: playable up to 1920 × 1080p Music Codecs FLAC and WAV Playable up to ~192kHz / ～24bit

Safe Driving

Enhanced Vehicle Intergration
Compatible with both the Automotive Data Solutions iDatalink Maestro RR and RR2 (sold separately)* for enhanced system vehicle integration. In addition to providing the seamless factory integration experience you have become accustomed to with the RR, these models feature expanded support when connected to the RR2, including an Advanced Driver Assistance Systems (ADAS) Widget, Customizable Accessory Controls, and compatibility with specific ESCORT radar detector systems (sold separately).

*Available features vary by vehicle

HD Rear Camera Input
The optional CMOS-740HD camera can be connected to the receiver’s rear camera input, displaying the image in true 1280 x 720 (720P) High Definition on compatible receivers. The camera’s built in High Dynamic Range technology further helps to overcome the negative effects of dark or bright conditions, making it the safest rear camera option available.

Rear View Camera Input with Parking Guidelines
An optional rear view camera enhances safety while backing up and monitoring behind your vehicle. Built-in, adjustable parking guidelines further add to its effectiveness.

4 Camera Inputs
To enable a smarter driving experience, receivers featuring 4 camera inputs allow for the utmost in convenience, flexibility, and safety. With 4 camera inputs, you can connect a front camera, a KENWOOD dashboard camera (DRV-N520 sold separately), and rear and side (blind spot) cameras. Alternatively, 4 camera inputs can support several other configurations, including the connection of 2 side cameras, a front camera, and a reverse camera. Camera switching is available using on screen controls, or automatically for side cameras when an optional iDatalink Maestro RR is connected (supported vehicles only).

Dash Cam Link Ready
Full HD video recording is available with a DRV-N520 compact windshield mount camera that can record every event in front of you while you drive. High Dynamic Range (HDR) allows flawless recording regardless of extreme bright light or very dark conditions. With a built-in gyro sensor, if an accident occurs it will be saved in a separate portion of memory within the 8GB SD card for viewing. Additional safety and warning features can be activated to avoid frontal collisions or remind you if traffic has moved in front of you.

Additional Features

High Definition Display
HD display delivers vivid colors with high-contrast and sharpness. Featuring an all-new electrostatic capacitive touch panel and HD LCD panel, with a high luminance white LED backlight.

Convenient and Easy-to-Use Capacitive Touch Panel
Provides a high contrast ratio, crystal clear display and vivid text. Easy to use widgets provide access to information screens with a swipe.

Customizable Multi Widget Screen
You can customize your home screen by selecting four widgets. Depending on the model, widget options can include album art of current song, clock, compass, photo frame, visualizer, and more.

USB Type-C
USB Type-C cable and USB Type-A adopter are included to the set.Rapidly charge your compatible Android smartphone with the USB port, up to a maximum of 3.0A

SiriusXM Radio Ready
Access additional music, sports and entertainment content on the go with SiriusXM Radio.
(Optional SiriusXM tuner required, sold separately)

Built-in HD Radio Tuner
HD Radio has the best selection of local radio with amazing features and no monthly fees. HD Radio provides CD sound quality from digital FM stations and FM sound quality from digital AM stations. You can even access additional HD multicasting stations that are not available on traditional analog radio.

Kenwood CMOS-740HD HD Backup Camera

High Definition View
Displaying the image in true 1280 x 720 (720P) High Definition on compatible DNR1007XR, DNR1008RVS, DMX1057XR, DMX1037S, DNX997XR, DDX9907XR, and DMX958XR receivers.

WVGA Camera

HD Camera

HDR (High Dynamic Range)
HDR helps to reduce “blown out highlights” and “crushed blacks” and ensure clear images in challenging environments, including backlit scenes in daylight, streetlight scenes at night and places where light-dark contrast is particularly severe.

W/O HDR

With HDR

12V & 24V Compatible
Cameras work with both 12V and 24V applications.

General Features
Photographed Image: HD (1280 x 720)
Lens: Wide angle, focal length: 1.86mm F:2.0
Frame Rate: 30fps
Angles of View: Horizontal 180°/ Vertical 103°
Operating Voltage: 12V/24V
Operating Temperature: -22℉ to +185℉ / -30℃ to +85℃
IPX: IP67
Output: HD-TVI
Weight: 0.073lbs / 33.2g (without cable)
Dimensions (W x H x D): 1-1/4" x 15/16" x 1" / 31.1mm x23.0mm x25.2mm

Cable Length
Camera Unit side: 9.84ft / 3m
DC Box Unit side: 19.69ft / 6m
Other: 1.64ft / 0.5m
